Perform PCR Arrays for less than $2.00?

Pathway PCR Arrays


Library of targeted real time PCR primer sets

Perform up to 200 PCR Arrays! That's $2 per array! (Based on a 10 ul reaction volume)

Flexibility to design one's own experiments

Microplate containing 88 targeted plus 8 housekeeping gene primer sets (20ul per well, 10uM concentration)

Note: Primer sequences unavailable for primer libraries

Quantitative Real Time PCR Primer Sets - ONLY $24.95



Our goal is to provide a cost-effective approach to validate microarray data and quantitate gene expression using real time PCR assays

Perform up to 1000 assays

Detailed information on optimal reaction conditions provided

Primer sequences provided!





Overview - Quantitative "Real Time" PCR

Quantitative real time PCR has revolutionized our ability to measure nucleic acid concentrations and is an important step for the validation of expression data generated by microarray analysis and other genomics techniques. This has been facilitated by the development of real time PCR instruments that measure the amount of PCR product produced at each step of the reaction or in "real time". SYBR green is currently the most popular real time PCR method due to its relative ease and reliability. Prior to the development of real time PCR technology, quantitative measurements required one to set up multiple PCR reactions in order to capture PCR product at a linear phase of amplification. Separation and quantitation of the PCR products was then done by gel electrophoresis or HPLC. These experiments are quite laborious and the number of manipulations required to achieve proper quantitation increased the likelihood of introducing error. Thus, the development of real time PCR instruments that could measure PCR product at each thermocycle enhanced the ease, accuracy and reproducibility of quantitative PCR. A variety of applications have emerged as a result of the discovery of real time PCR. These include 1) validation of gene expression data obtained by microarray analysis, 2) measurement of DNA copy number, 3) detection and quantitation of viral particles and potentially lethal microorganisms, 4) mutation/SNP analysis, and 5) miRNA expression.

In general, real time PCR protocols are similar to that of standard PCR reactions. The same issues apply with respect to producing clean template, designing primers and optimizing reaction conditions. The major difference is the incorporation of an intercalating agent such as SYBR green or the use fluorescent primers for the detection of PCR product. In a typical reaction, PCR product is produced exponentially. Because it takes several cycles for enough product to be readily detectable, the plot of fluorescence vs. cycle number exhibits a sigmoidal appearance. At later cycles, the reaction substrates become depleted, PCR product no longer doubles, and the curve begins to flatten. The point on the curve in which the amount of fluorescence begins to increase rapidly, usually a few standard deviations above the baseline, is termed the threshold cycle (Ct value). The plot of Ct versus template is linear, thus a comparison of Ct values between multiple reactions enables one to calculate the concentration of the target nucleic acid. The slope of this line provides a measure of PCR efficiency.

PCR products may be quantitated by generating a standard curve or quantitated relative to a control gene. Real time PCR quantitation based on a standard curve may utilize plasmid DNA or other forms of DNA in which the absolute concentration of each standard is known. One must be sure, however, that the efficiency of PCR is the same for the standards as that of the "unknown" samples. Performing PCR from purified targets can in some cases be more efficient than that observed with complex nucleic acid mixtures. The relative quantitation method is somewhat simpler as it requires the measurement of housekeeper or control genes to normalize expression of the target gene. However, the selection of appropriate control genes can cause problems as they may not necessarily be equally expressed across all unknown samples. This may be circumvented by normalizing measurements to a set of housekeeping genes in order to avoid this variability problem.

A critical aspect of performing real time PCR is to begin with a template that is of high purity. This can be challenging when working with some biological samples. Fortunately, a number of commercial products have been developed to facilitate the isolation of nucleic acids in high purity. Removing contaminating phenol and unwanted DNA are steps to consider. For gene expression studies, reverse transcription must be carried out with high purity reagents and in multiple replicates as this step can introduce variability in template replication. Reverse transcription may be done prior to real time PCR or may be incorporated within the amplification program.
